FLAT BED CUTTING RULE
XINPENG series products are widely used in cutting cardboard. Corrugated board, card, plywood, cork, rubber and gaskets, plastic materials, etc. We supply Shaved edge and Polished edge according to the different cutting materials and different applying situation.
Cutting edge angle options: 52°/ 42°/ 35°
EDGE TYPE
|
 |
CFDB Long Center Bevel |
|
Cut hard or thick materials by reduce cutting force. E.g. leather, cork, rubber, jigsaw puzzles, corrugated board, plastics and plywood etc. |
|
 |
CF Center Bevel |
|
Commonly used for mostly standard cardboard. |
|
 |
SFDB Long Side Bevel |
|
Cut hard or thick materials; which the cut surface leaves with angel 90° |
|
 |
SF Side Bevel |
|
Particularly suitable for cutting gaskets, displays and close shapes. |
TYPE & TECHNOLOGY
SOFT
Multi purpose cutting rule used for cardboard, corrugated, label, card, etc.
|
Hardness |
Edge 640HV ( 57 HRC)
Body 300HV ( 30 HRC ) |
 |
|
Bendability |
ɑ=160°
R～0.3mm |
|
Thickness |
1.27pt 0.45mm
1.5 pt 0.53mm
2 pt 0.71mm
3pt 1.05mm
4pt 1.42mm |
|
Height |
22 – 60 mm |
|
Edge Type |
Shaved |
MEDIUM HARD
With excellent bendability based on soft body with a long lifetime due to the hardened tip. Used for cardboard, corrugated, label and cards etc.
|
Hardness |
Edge 640HV ( 57 HRC)
Body 340HV ( 34 HRC) |
 |
|
Bendability |
ɑ=140°
R～0.3mm |
|
Thickness |
1.27pt 0.45mm
1.5 pt 0.53mm
2 pt 0.71mm
3pt 1.05mm
4pt 1.42mm |
|
Height |
22 – 60 mm |
|
Edge Type |
Shaved |
HARD
For cutting heavy materials such as non-asbestos gasket materials, reinforced glass fiber and other abrasive materials, due to best stability and excellent lifetime. Used for plastics, gaskets, tinsel puzzles etc.
|
Hardness |
Edge 640HV ( 57 HRC)
Body 390HV ( 39 HRC) |
 |
|
Bendability |
ɑ=90°
R～0.3mm |
|
Thickness |
1.27pt 0.45mm
1.5 pt 0.53mm
2 pt 0.71mm
3pt 1.05mm
4pt 1.42mm |
|
Height |
22 – 60 mm |
|
Edge Type |
Shaved |
|
